It is a low noise complete solution with 36 V-21 A laser driver, TEC controller and air-cooling fan regulation. TEC and CTN elements are provided and compatible for single or multiple laser diode driving. This high power laser diode driver is generally used to deliver CW current. It is also able to deliver pulses which are generated internally by an on-board pulse generator, or on-demand from an external analog modulation signal. It is the most compact device with such performances and this makes it an ideal tool for OEM integration into your product.
From: 2 995€
All shippings with DHL Express
High power laser diode driver Key features :
Applications of this high power laser diode driver include fiber laser pumping, nondestructive control etc. CCM high power laser diode driver is part of our “Multiboard” laser driver and synchronization module family. These are are ideal solutions to help R&D teams reach their best performance by facilitating fast and cost effective development of integrated solutions. The GUI software lets the user have total control of all module functions.
It works alone or in series with other products in our range like :
Complex systems, such as fiber lasers, can be quickly developed on this module platform. It can be easily connected to our double channel fiber laser diode driver platform which allows to create nearly any type of fiber laser.
See our Tutorials to get an overview of its capabilities. :
AeroDIODE products leverage proprietary, cutting edge technology which has been under development in the well known ALPhANOV technology center for over 12 years. AeroDIODE is a member of EPIC European industry association and “Route des Lasers” cluster .
| CCM-std (Standard version) | New : CCM-HP (High Power) |
|
|---|---|---|
| Output current | 0 - 13 A | 0 - 21 A |
| Output Voltage | 0 - 23 V | 0 - 36V |
| Laser diode regulation T° range | 15-40 °C | |
| Laser diode temperature stability (integration dependant) | 10 mK | |
| Low power adjustment precision | 0.05 A | |
| Laser power stability | < 0.05% | |
| Max modulation rate | 100 kHz | |
| Interface/GUI/libraries | USB/UART - Windows 7/10 ; DLLs - Hexa - Labview - Python | |
| Power supply | 24 V (220/110V power supply not included) | |
| Dimensions (mm) | 238 * 119 * 112 | 238 * 146 * 142.5 |
Picture | Short descritption / PN | Description | Documents | Price (ex VAT) | Avalaible | Qty | |
|---|---|---|---|---|---|---|---|
 | Low power version (10 V - 13A) for laser diodes up to 20W PN : CCM-Mini | NEW : "Mini" version for laser diodes up to 20 W optical power (max 10V/13A). Includes 1*TEC cooler 30*30. Read more NEW : "Mini" version for laser diodes up to 20 W optical power (max 10V/13A). Includes 1*TEC cooler 30*30. Less | 2 995€ | 1 - 2 weeks | |||
 | Standard version (23 V-13 A) for laser diodes up to 60 W PN : CCM-std | Standard version for laser diodes up to 60W optical power (max 23V/13A). Includes 2*TEC cooler 30*30. Read more Standard version for laser diodes up to 60W optical power (max 23V/13A). Includes 2*TEC cooler 30*30. Less | 3 395€ | 1 - 2 weeks | |||
 | High Power version (36 V-21 A) for laser diodes up to 120 W PN : CCM-HP | HP (High Power) version for laser diodes up to 120 W optical power (max 36V-21A). Includes 2*TEC cooler 40*40. Read more HP (High Power) version for laser diodes up to 120 W optical power (max 36V-21A). Includes 2*TEC cooler 40*40. Less | 4 295€ | 1 - 2 weeks | |||
 | Ultra-High Power version for laser diodes up to 180 W PN : CCM-UHP | UHP (Ultra High Power) version for laser diodes up to 180 W optical power (max 36V-21A). Includes 2*TEC cooler 50*50. Read more UHP (Ultra High Power) version for laser diodes up to 180 W optical power (max 36V-21A). Includes 2*TEC cooler 50*50. Less | 4 495€ | 1 - 2 weeks | |||
Picture | ShortPN | Description | Docs | Price | Avalaible | Qty | |
 | OPTION 1 - TEC Cooler 30*30 mm² PN : OPTION-1 | High heat pumping density thermoelectric module (TEC). The module is assembled with a large number of semiconductor couples to achieve a much higher heat pumping capacity than standard single stage… Read more High heat pumping density thermoelectric module (TEC). The module is assembled with a large number of semiconductor couples to achieve a much higher heat pumping capacity than standard single stage TECs. All CCM-std units include 2 units as standard, but for large size laser diode or multiple laser diode configurations, it may be necessary to use more than 2 TECs. Less | 265€ | 1 - 2 weeks | |||
| OPTION 2 - TEC Cooler 40*40 mm² PN : OPTION-2 | High heat pumping density thermoelectric module . The module is assembled with a large number of semiconductor couples to achieve a much higher heat pumping capacity than standard single stage TECs… Read more High heat pumping density thermoelectric module . The module is assembled with a large number of semiconductor couples to achieve a much higher heat pumping capacity than standard single stage TECs. All CCM-HP units include 2 units as standard, but for large size laser diode or multiple laser diode configurations, it may be necessary to use more than 2 TECs. Less | 345€ | 1 - 2 weeks | |||
 | OPTION 3 - TOMBAK synchronization module PN : OPTION-3 | Optional synchronization tool to have maximum flexibility to handle any type of pulse synchronization and trigger outputs. See the dedicated page in the "synchronization" section of AeroDIODE website. When this… Read more Optional synchronization tool to have maximum flexibility to handle any type of pulse synchronization and trigger outputs. See the dedicated page in the "synchronization" section of AeroDIODE website. When this option is chosen, the TOMBAK is mounted on the side of the product and connected to the CCM. The GUI opens two windows, one for the CCM and one for the TOMBAK. External triggers are connected to the SMA connector and one can adjust delay, divide signals, get any pulse duration etc. etc. etc. Less | 1 545€ | 1 - 2 weeks | |||
 | OPTION 4 - Double Board version PN : OPTION-4 | An additional board is mounted on the other side of the cooler. This allows to control two laser diodes with independent temperature and current control on a single compact setup… Read more An additional board is mounted on the other side of the cooler. This allows to control two laser diodes with independent temperature and current control on a single compact setup. The GUI opens automatically two windows on the same computer screen. Available on CCM-std, CCM-HP and CCM-UHP only. Less | 1 495€ | 1 - 2 weeks | |||
 | OPTION 5 - Ultra-low Noise version PN : OPTION-5 | When this option is chosen, the product is modified to reach the best level of stability and noise levels down to, for example, a typical value of 0.02% rms noise at 18… Read more When this option is chosen, the product is modified to reach the best level of stability and noise levels down to, for example, a typical value of 0.02% rms noise at 18 A. This modification has an impact on the modulation bandwidth which is significantly reduced. Less | 395€ | 1 - 2 weeks |
To receive your quotation instantaneously by email, please add products to cart and follow instructions.
(Note : by following this instant quote process on this shopping site, American customers can select to receive this instant quote from our US-based partner Research Lab Source. RLS offers the same price & delivery as Aerodiode and is a registered vendor in most university and government research lab purchasing)
