1290 nm laser diode – 4 DFB models up to 120 mW – CW or Pulse

1290 nm DFB laser diode - Butterfly module

These fiber-coupled 1290 nm laser diodes are offered as stock items or associated with a low noise CW or Pulsed Laser Diode Driver. All 4 models are single frequency versions (DFB laser diode) up to 120 mW. They are compatible with our high speed nanosecond pulsed drivers and this makes it an optimal solution for Telecommunication or 3D-sensing R&D.

These single mode 1290 nm laser diodes can reach high power in nanosecond pulse regime up to 250 mW. Most Turn-key diode + driver solutions are optimized from single-shot to CW performances with pulse width lengths down to 1 nanosecond. The 1290 nm laser diode precision pulses are generated internally by an on-board pulse generator, or on demand from an external TTL signal. It becomes easy to generate complex burst shapes.

From: 1 345

In stock

All shippings with DHL Express

Filters Sort results
Reset Apply
Short descritption / PN
Description
Documents
Price (ex VAT)
Avalaible
Qty
1290 nm DFB laser diode - Butterfly module
Model 1 (10 mW)
PN :
1290LD-1-0-0

1290 nm 10 mW butterfly laser diode alone . SMF28 fiber with FC-APC connector. Also available in PM version (select the Option) and also available at any other wavelengths between 1270 and 1650 nm -…

Read more

1290 nm 10 mW butterfly laser diode alone . SMF28 fiber with FC-APC connector. Also available in PM version (select the Option) and also available at any other wavelengths between 1270 and 1650 nm - contact us for these special wavelength versions.

Less
1 345
Today
Max:
Min: 1
Step: 1
OPTION : PM fiber for Model 1
PN :
OPTION-PM1

With this OPTION, Model 1 is offered with a polarization maintaining PM1300 fiber instead of a standard SMF28. Both the connector key and the light polarization are aligned along the slow…

Read more

With this OPTION, Model 1 is offered with a polarization maintaining PM1300 fiber instead of a standard SMF28. Both the connector key and the light polarization are aligned along the slow axis (standard configuration in our industry).

Less
200
3 - 4 weeks
Max:
Min: 1
Step: 1
Model 1 (10 mW) with "CCS-CW" driver
PN :
1290LD-1-1-1

Open CW driver with 1290 nm 10 mW butterfly laser diode. SMF fiber with FC-APC connector. Also available in PM version (select the Option) and also available at any other wavelengths between 1270…

Read more

Open CW driver with 1290 nm 10 mW butterfly laser diode. SMF fiber with FC-APC connector. Also available in PM version (select the Option) and also available at any other wavelengths between 1270 and 1650 nm - contact us for these special wavelength versions.

Less
3 440
2 - 5 days
Max:
Min: 1
Step: 1
Model 1 (10 mW) with "CCS" driver
PN :
1290LD-1-2-1

Open Pulse & CW driver with 1290 nm 10 mW butterfly laser diode. SMF fiber with FC-APC connector ; Down to 1.5 ns pulse duration ; Up to 4 MHz pulse repetition rate. Compatible with OPTION 2 (250…

Read more

Open Pulse & CW driver with 1290 nm 10 mW butterfly laser diode. SMF fiber with FC-APC connector ; Down to 1.5 ns pulse duration ; Up to 4 MHz pulse repetition rate. Compatible with OPTION 2 (250 MHz version - see below) ; Also available in PM version (select the Option) and also available at any other wavelengths between 1270 and 1650 nm - contact us for these special wavelength versions.

Less
4 340
2 - 5 days
Max:
Min: 1
Step: 1
Model 1 (10 mW) with "Shaper" driver
PN :
1290LD-1-3-1

Open pulsed driver with 10 mW 1290 nm laser diode. User-design nanosecond pulse shape with 0.5 ns resolution and up to 8 µs pulse width (The AWG pulse generator is integrated). Down to 1.5 ns…

Read more

Open pulsed driver with 10 mW 1290 nm laser diode. User-design nanosecond pulse shape with 0.5 ns resolution and up to 8 µs pulse width (The AWG pulse generator is integrated). Down to 1.5 ns pulse duration. Up to 20 MHz pulse repetition rate. Also available in PM version (select the Option) and also available at any other wavelengths between 1270 and 1650 nm - contact us for these special wavelength versions.

Less
6 340
1 - 2 weeks
Max:
Min: 1
Step: 1
1290 nm laser diode CCSI module
Model 1 (10 mW) within "CCSI-CW" module
PN :
1290LD-1-1-2

Turn-key integrated CW laser diode module at 1290nm. CW power up to 10 mW. SMF metal protected fiber output with FC/APC output connector. Compatible with option-1 (3 mm collimator) and option 3 (…

Read more

Turn-key integrated CW laser diode module at 1290nm. CW power up to 10 mW. SMF metal protected fiber output with FC/APC output connector. Compatible with option-1 (3 mm collimator) and option 3 (Benchtop version) see below.
Also available in PM version (select the Option) and also available at any other wavelengths between 1270 and 1650 nm - contact us for these special wavelength versions.

Less
4 640
1 - 2 weeks
Max:
Min: 1
Step: 1
1290 nm laser diode CCSI module
Model 1 (10 mW) within "CCSI" module
PN :
1290LD-1-2-2

Turn-key integrated laser diode module at 1290 nm for Pulse and CW emission. SMF metal protected fiber output with FC/APC output connector. CW output power up to 10 mW. Down to 1.5…

Read more

Turn-key integrated laser diode module at 1290 nm for Pulse and CW emission. SMF metal protected fiber output with FC/APC output connector. CW output power up to 10 mW. Down to 1.5 ns pulse duration. Up to 4 MHz pulse repetition rate. Compatible with option-1 (3 mm collimator), option-2 (250 MHz version) and option 3 (Benchtop version) - see below. Also available in PM version (select the Option) and also available at any other wavelengths between 1270 and 1650 nm - contact us for these special wavelength versions.

Less
5 540
1 - 2 weeks
Max:
Min: 1
Step: 1
ShortPN
Description
Docs
Price
Avalaible
Qty
1290 nm DFB laser diode - Butterfly module
Model 2 (40 mW)
PN :
1290LD-2-0-0

1290 nm 40 mW butterfly laser diode alone . SMF fiber with FC-APC connector. Also available in PM version (select the Option) and also available at any other wavelengths between 1270 and 1650 nm -…

Read more

1290 nm 40 mW butterfly laser diode alone . SMF fiber with FC-APC connector. Also available in PM version (select the Option) and also available at any other wavelengths between 1270 and 1650 nm - contact us for these special wavelength versions.

Less
1 995
3 - 4 weeks
Max:
Min: 1
Step: 1
OPTION : PM fiber for Model 2
PN :
OPTION-PM2

With this OPTION, Model 2 is offered with a polarization maintaining PM1300 fiber instead of a standard SMF28. Both the connector key and the light polarization are aligned along the slow…

Read more

With this OPTION, Model 2 is offered with a polarization maintaining PM1300 fiber instead of a standard SMF28. Both the connector key and the light polarization are aligned along the slow axis (standard configuration in our industry).

Less
300
3 - 4 weeks
Max:
Min: 1
Step: 1
Model 2 (40 mW) with "CCS-CW" driver
PN :
1290LD-2-1-1

Open CW driver with 1290 nm butterfly laser diode and SMF fiber with FC/APC connector. Up to 40 mW CW optical power. Also available in PM version (select the Option) and…

Read more

Open CW driver with 1290 nm butterfly laser diode and SMF fiber with FC/APC connector. Up to 40 mW CW optical power. Also available in PM version (select the Option) and also available at any other wavelengths between 1270 and 1650 nm - contact us for these special wavelength versions.

Less
4 090
3 - 4 weeks
Max:
Min: 1
Step: 1
Model 2 (40 mW) with "CCS" driver
PN :
1290LD-2-2-1

Open Pulse & CW driver with 1290 nm butterfly laser diode and SMF fiber output with FC-APC connector. Up to 40 mW CW optical power ; Down to 1.5 ns pulse duration ; Up to 4…

Read more

Open Pulse & CW driver with 1290 nm butterfly laser diode and SMF fiber output with FC-APC connector. Up to 40 mW CW optical power ; Down to 1.5 ns pulse duration ; Up to 4 MHz pulse repetition rate. Compatible with OPTION 2 (250 MHz version) ; Also available in PM version (select the Option) and also available at any other wavelengths between 1270 and 1650 nm - contact us for these special wavelength versions.

Less
4 990
3 - 4 weeks
Max:
Min: 1
Step: 1
Model 2 (40 mW) with "Shaper" driver
PN :
1290LD-2-3-1

Open pulsed driver with 40 mW 1290 nm laser diode. User-design nanosecond pulse shape with 0.5 ns resolution and up to 8 µs pulse width (The AWG pulse generator is integrated). Down to 1.5 ns…

Read more

Open pulsed driver with 40 mW 1290 nm laser diode. User-design nanosecond pulse shape with 0.5 ns resolution and up to 8 µs pulse width (The AWG pulse generator is integrated). Down to 1.5 ns pulse duration. Up to 20 MHz pulse repetition rate. Also available in PM version (select the Option) and also available at any other wavelengths between 1270 and 1650 nm - contact us for these special wavelength versions.

Less
6 990
3 - 4 weeks
Max:
Min: 1
Step: 1
1290 nm laser diode CCSI module
Model 2 (40 mW) within "CCSI-CW" module
PN :
1290LD-2-1-2

Turn-key integrated CW laser diode module at 1290 nm. CW power up to 40 mW. SMF metal protected fiber output with FC/APC output connector. Compatible with option-1 (3 mm collimator). and option 3 (…

Read more

Turn-key integrated CW laser diode module at 1290 nm. CW power up to 40 mW. SMF metal protected fiber output with FC/APC output connector. Compatible with option-1 (3 mm collimator). and option 3 (Benchtop version). Also available in PM version (select the Option) and also available at any other wavelengths between 1270 and 1650 nm - contact us for these special wavelength versions.

Less
5 290
3 - 4 weeks
Max:
Min: 1
Step: 1
1290 nm laser diode CCSI module
Model 2 (40 mW) within "CCSI" module
PN :
1290LD-2-2-2

Turn-key integrated laser diode module at 1290 nm for Pulse and CW emission. SMF metal protected fiber output with FC/APC output connector. CW output power up to 40 mW. Down to 1.5…

Read more

Turn-key integrated laser diode module at 1290 nm for Pulse and CW emission. SMF metal protected fiber output with FC/APC output connector. CW output power up to 40 mW. Down to 1.5 ns pulse duration. Up to 4 MHz pulse repetition rate. Compatible with option-1 (3 mm collimator), option-2 (250 MHz version) and option 3 (benchtop version). Also available in PM version (select the Option) and also available at any other wavelengths between 1270 and 1650 nm - contact us for these special wavelength versions.

Less
6 190
3 - 4 weeks
Max:
Min: 1
Step: 1
ShortPN
Description
Docs
Price
Avalaible
Qty
1290 nm DFB laser diode - Butterfly module
Model 3 (100 mW)
PN :
1290LD-3-0-0

1290 nm 100 mW butterfly laser diode alone . SMF fiber with FC-APC connector. Also available in PM version (select the Option) and also available at any other wavelengths between 1270 and 1650 nm -…

Read more

1290 nm 100 mW butterfly laser diode alone . SMF fiber with FC-APC connector. Also available in PM version (select the Option) and also available at any other wavelengths between 1270 and 1650 nm - contact us for these special wavelength versions.

Less
2 845
3 - 4 weeks
Max:
Min: 1
Step: 1
OPTION : PM fiber for model 3
PN :
OPTION-PM3

With this OPTION, Model 3 is offered with a polarization maintaining PM1300 fiber instead of a standard SMF28. Both the connector key and the light polarization are aligned along the slow…

Read more

With this OPTION, Model 3 is offered with a polarization maintaining PM1300 fiber instead of a standard SMF28. Both the connector key and the light polarization are aligned along the slow axis (standard configuration in our industry).

Less
500
3 - 4 weeks
Max:
Min: 1
Step: 1
Model 3 (100 mW) with "CCS-CW" driver
PN :
1290LD-3-1-1

Open CW driver with 1290 nm butterfly laser diode and SMF fiber with FC/APC connector. Up to 100 mW CW optical power. Also available in PM version (select the Option) and…

Read more

Open CW driver with 1290 nm butterfly laser diode and SMF fiber with FC/APC connector. Up to 100 mW CW optical power. Also available in PM version (select the Option) and also available at any other wavelengths between 1270 and 1650 nm - contact us for these special wavelength versions.

Less
4 940
3 - 4 weeks
Max:
Min: 1
Step: 1
Model 3 (100 mW) with "CCS" driver
PN :
1290LD-3-2-1

Open Pulse & CW driver with 1290 nm butterfly laser diode and SMF fiber output with FC-APC connector. Up to 100 mW CW optical power ; Down to 1.5 ns pulse duration ; Up to 4…

Read more

Open Pulse & CW driver with 1290 nm butterfly laser diode and SMF fiber output with FC-APC connector. Up to 100 mW CW optical power ; Down to 1.5 ns pulse duration ; Up to 4 MHz pulse repetition rate. Compatible with OPTION 2 (250 MHz version) ; Also available in PM version (select the Option) and also available at any other wavelengths between 1270 and 1650 nm - contact us for these special wavelength versions.

Less
5 840
3 - 4 weeks
Max:
Min: 1
Step: 1
Model 3 (100 mW) with "Shaper" driver
PN :
1290LD-3-3-1

Open pulsed driver with 100 mW 1290 nm laser diode. User-design nanosecond pulse shape with 0.5 ns resolution and up to 8 µs pulse width (The AWG pulse generator is integrated). Down to 1.5 ns…

Read more

Open pulsed driver with 100 mW 1290 nm laser diode. User-design nanosecond pulse shape with 0.5 ns resolution and up to 8 µs pulse width (The AWG pulse generator is integrated). Down to 1.5 ns pulse duration. Up to 20 MHz pulse repetition rate. Also available in PM version (select the Option) and also available at any other wavelengths between 1270 and 1650 nm - contact us for these special wavelength versions.

Less
7 840
3 - 4 weeks
Max:
Min: 1
Step: 1
1290 nm laser diode CCSI module
Model 3 (100 mW) within "CCSI-CW" module
PN :
1290LD-3-1-2

Turn-key integrated CW laser diode module at 1290 nm. CW power up to 100 mW. SMF metal protected PM fiber output with FC/APC output connector. Compatible with option-1 (3 mm collimator) and…

Read more

Turn-key integrated CW laser diode module at 1290 nm. CW power up to 100 mW. SMF metal protected PM fiber output with FC/APC output connector. Compatible with option-1 (3 mm collimator) and option 3 (benchtop version). Also available in PM version (select the Option) and also available at any other wavelengths between 1270 and 1650 nm - contact us for these special wavelength versions.

Less
6 140
3 - 4 weeks
Max:
Min: 1
Step: 1
1290 nm laser diode CCSI module
Model 3 (100 mW) within "CCSI" module
PN :
1290LD-3-2-2

Turn-key integrated laser diode module at 1290 nm for Pulse and CW emission. SMF metal protected fiber output with FC/APC output connector. CW output power up to 100 mW. Down to 1.5…

Read more

Turn-key integrated laser diode module at 1290 nm for Pulse and CW emission. SMF metal protected fiber output with FC/APC output connector. CW output power up to 100 mW. Down to 1.5 ns pulse duration. Up to 4 MHz pulse repetition rate. Compatible with option-1 (3 mm collimator), option-2 (250 MHz version) and option 3 (benchtop version). Also available in PM version (select the Option) and also available at any other wavelengths between 1270 and 1650 nm - contact us for these special wavelength versions.

Less
7 040
3 - 4 weeks
Max:
Min: 1
Step: 1
ShortPN
Description
Docs
Price
Avalaible
Qty
1290 nm DFB laser diode - Butterfly module
Model 4 (120 mW)
PN :
1290LD-4-0-0

1290 nm 120 mW butterfly laser diode alone . SMF fiber with FC-APC connector. Also available in PM version - Select the option below.

2 845
3 - 4 weeks
Max:
Min: 1
Step: 1
OPTION : PM fiber for model 4
PN :
OPTION-PM4

With this OPTION, Model 4 is offered with a polarization maintaining PM1300 fiber instead of a standard SMF28. Both the connector key and the light polarization are aligned along the slow…

Read more

With this OPTION, Model 4 is offered with a polarization maintaining PM1300 fiber instead of a standard SMF28. Both the connector key and the light polarization are aligned along the slow axis (standard configuration in our industry).

Less
500
3 - 4 weeks
Max:
Min: 1
Step: 1
Model 4 (120 mW) with "CCS-CW" driver
PN :
1290LD-4-1-1

Open CW driver with 1290 nm -choose your wavelength) butterfly laser diode and SMF fiber with FC/APC connector. Up to 120 mW CW optical power. Also available in PM version -…

Read more

Open CW driver with 1290 nm -choose your wavelength) butterfly laser diode and SMF fiber with FC/APC connector. Up to 120 mW CW optical power. Also available in PM version - select the option

Less
4 940
3 - 4 weeks
Max:
Min: 1
Step: 1
Model 4 (120 mW) with "CCS" driver
PN :
1290LD-4-2-1

Open Pulse & CW driver with 1290 nm butterfly laser diode and SMF fiber output with FC-APC connector. Up to 120 mW CW optical power ; Down to 1.5 ns pulse duration ; Up to 4…

Read more

Open Pulse & CW driver with 1290 nm butterfly laser diode and SMF fiber output with FC-APC connector. Up to 120 mW CW optical power ; Down to 1.5 ns pulse duration ; Up to 4 MHz pulse repetition rate. Compatible with OPTION 2 (250 MHz version) ; Also available in PM version - select the option.

Less
5 840
3 - 4 weeks
Max:
Min: 1
Step: 1
Model 4 (120 mW) with "Shaper" driver
PN :
1290LD-4-3-1

Open pulsed driver with 120 mW 1290 nm laser diode. User-design nanosecond pulse shape with 0.5 ns resolution and up to 8 µs pulse width (The AWG pulse generator is integrated). Down to 1.5 ns…

Read more

Open pulsed driver with 120 mW 1290 nm laser diode. User-design nanosecond pulse shape with 0.5 ns resolution and up to 8 µs pulse width (The AWG pulse generator is integrated). Down to 1.5 ns pulse duration. Up to 20 MHz pulse repetition rate. Also available in PM fiber version - select the option.

Less
7 840
3 - 4 weeks
Max:
Min: 1
Step: 1
1290 nm laser diode CCSI module
Model 4 (120 mW) within "CCSI-CW" module
PN :
1290LD-4-1-2

Turn-key integrated CW laser diode module at 1290 nm. CW power up to 120 mW. SMF metal protected fiber output with FC/APC output connector. Compatible with option-1 (3 mm collimator) and option 3 (…

Read more

Turn-key integrated CW laser diode module at 1290 nm. CW power up to 120 mW. SMF metal protected fiber output with FC/APC output connector. Compatible with option-1 (3 mm collimator) and option 3 (benchtop version). Also available in PM fiber version - select the option.

Less
6 140
3 - 4 weeks
Max:
Min: 1
Step: 1
1290 nm laser diode CCSI module
Model 4 (120 mW) within "CCSI" module
PN :
1290LD-4-2-2

Turn-key integrated laser diode at 1290 nm for Pulse and CW emission. SMF metal protected fiber output with FC/APC output connector. CW output power up to 120 mW. Down to 1.5 ns…

Read more

Turn-key integrated laser diode at 1290 nm for Pulse and CW emission. SMF metal protected fiber output with FC/APC output connector. CW output power up to 120 mW. Down to 1.5 ns pulse duration. Up to 4 MHz pulse repetition rate. Compatible with option-1 (3 mm collimator), option-2 (250 MHz version) and option 3 (benchtop version). Also available in PM fiber version - select the option.

Less
7 040
3 - 4 weeks
Max:
Min: 1
Step: 1
ShortPN
Description
Docs
Price
Avalaible
Qty
OPTION 1 : 3 mm optical collimator
PN :
OPTION-1

Small form factor 3 mm beam diameter optical collimator with AR coatings.

445
Today
Max:
Min: 1
Step: 1
OPTION 2 : 250 MHz repetition rate
PN :
OPTION-2

250 MHz internal pulse generator (instead of 4 MHz or 10 MHz) for "Pulse & CW" laser diode drivers and "Pulse & CW" laser diode modules only.

995
2 - 5 days
Max:
Min: 1
Step: 1
OPTION 3 : Benchtop version for final user instead of OEM module
PN :
OPTION-3

All our modules are ideal products for OEM integration. This option adds more functionalities when the product is used as a benchtop : Key for the user, On/Off switch on…

Read more

All our modules are ideal products for OEM integration. This option adds more functionalities when the product is used as a benchtop : Key for the user, On/Off switch on the front face etc. This option is available for CCSI and CCSI-CW integrated modules only.

Less
495
1 - 2 weeks
Max:
Min: 1
Step: 1

To receive your quotation instantaneously by email, please add products to cart and follow instructions.

(Note : by following this instant quote process on this shopping site, American customers can select to receive this instant quote from our US-based partner Research Lab Source. RLS offers the same price & delivery as Aerodiode and is a registered vendor in most university and government research lab purchasing)
